Ximax Oxford-Plus Duo Designer Radiator 595 x 1800mm 5775Btu White

By Ximax Product code: 62801 Pack size: Each

£459.98 Exc. VAT £383.32
Selected
Quantity

Product Details

Stylish designer radiator with modern panel design and top cover in duo version. 10 year manufacturer's guarantee (T&Cs Apply). Suitable for hot water central heating systems.

• Steel construction with high quality pre-treatment and powder-coated finish.
• Easy to install
• Wall fixings, plug & vent included
• Connection size: 1/2"
• Heat output calculated at Delta T50°C
• Pressure tested to 5,2 bar, max working pressure 4 bar
• Max. working temperature : 120°C
• Manufactured and tested to EN-442
• Projection from wall: 90 mm and wall to centre: 60 mm

Technical Specification
Brand Ximax
Colour White
Width (mm) 1800
Height (mm) 595
Material Steel
Manufacturer ID TPPHD5951800W
BTU 5775
Width (mm) 1800
Warranty (years) 10
Certification Manufactured and tested to EN-442
Depth (mm) 75
Min Pressure (bar) 0.5
Max Pressure (bar) 4
Finish Gloss
Weight (kg) 44.77
User Guide click here
Pack Contents Radiator, fixings, blank and air plug
Fitted Depth (mm) 86
BTU Range 4001-6000
Inlet Connection 1/2"
Max. Hot Water Temp 120°C
Range Name Oxford Plus
Coating Powder Coated
Delta T 50
Suitable Systems Central Heating
Radiator Profile Double
Number of Sections 8
Radiator Orientation Horizontal
Radiator Style Flat Panel
