Ximax Oxford Duo Designer Radiator 600 x 445mm 1536Btu White

By Ximax Product code: 72117 Pack size: Each

£188.98 was £209.98 Exc. VAT £157.48
Selected
Quantity

Product Details

• Connection size: 1/2"
• Heat output calculated at Delta T50°C
• Pressure tested to 5.2 bar, maximum working pressure 4 bar
• Maximum working temperature: 120°C
• Manufactured and tested to EN-442
• Projection from wall: 90mm - Wall to centre: 60mm
Dimensions are height by width.

Stylish designer radiator with modern panel design duo version, suitable for hot water central heating systems. Steel construction with high quality pre-treatment and a powder-coated finish. Easy to install, with wall fixings, plug and vent included.
10 year manufacturer's guarantee (T&Cs apply).

Technical Specification
Brand Ximax
Colour White
Width (mm) 445
Height (mm) 600
Material Steel
Manufacturer ID TPD600445W
BTU 1536
Width (mm) 445
Warranty (years) 10
Certification Manufactured and tested to EN-442
Depth (mm) 75
Min Pressure (bar) 0.5
Max Pressure (bar) 4
Finish Gloss
Weight (kg) 12.09
User Guide click here
Pack Contents Radiator, fixings, blank and air plug
Fitted Depth (mm) 90
BTU Range 1001-2000
Inlet Connection 1/2"
Max. Hot Water Temp 120°C
Range Name Oxford
Coating Powder Coated
Delta T 50
Suitable Systems Central Heating
Radiator Profile Double
Number of Sections 6
Radiator Orientation Vertical
Radiator Style Flat Panel
