Ximax Oxford Duo Designer Radiator 1800 x 445mm 4539Btu White

By Ximax Product code: 37814 Pack size: Each

£314.80 was £349.78 Exc. VAT £262.33

Product Details

A radiator from the Ximax Oxford Duo collection does far more than just heat your home. It instantly becomes a focal point in the room – with its modern panel design, this tall designer radiator adds style and sophistication to the decor of any modern home.

Suitable for use with hot water heating systems, the radiator’s performance is just as impressive as its appearance. A high heat output will keep your room at the perfect temperature, and the powder-coated finish helps to radiate heat more effectively. It’s easy to install too, and comes with wall fixings, plug and vent included.

• Modern panel design will become a stylish feature of any room

• Suitable for hot water central heating systems

• Steel construction with high-quality pre-treatment for robust durability

• Powder-coated finish radiates heat from the surface more effectively

• Heat output calculated at Delta T50°C

• Pressure-tested to 5.2 bar, with a maximum working pressure of 4 bar

• Maximum working temperature: 120°C

• Projection from wall: 90mm

• Wall to centre: 60mm

• Connection size: 1/2"

• Easy to install with wall fixings, plug and vent included

• 10-year manufacturer's guarantee (T&Cs apply)

• Manufactured and tested to EN-442

Technical Specification
Brand Ximax
Colour White
Width (mm) 445
Height (mm) 1800
Material Steel
Manufacturer ID TPD1800445W
BTU 4539
Width (mm) 445
Warranty (years) 10
Certification Manufactured and tested to EN-442
Depth (mm) 75
Min Pressure (bar) 0.5
Max Pressure (bar) 4
Finish Gloss
Weight (kg) 33.65
User Guide click here
Pack Contents Radiator, fixings, blank and air plug
Pipe Centres (mm) 445mm
Fitted Depth (mm) 90
BTU Range 4001-6000
Inlet Connection 1/2"
Max. Hot Water Temp 120°C
Range Name Oxford
Coating Powder Coated
Delta T 50
Suitable Systems Central Heating
Radiator Profile Double
Number of Sections 6
Radiator Orientation Vertical
Radiator Style Flat Panel
Ximax Oxford Duo Designer Radiator 1800 x 445mm 4539Btu White is rated 3.5 out of 5 by 6.
Rated 5 out of 5 by from Good Product Good product, I would recommend it. It puts out a good amount of heat and looks good. The profile is slim so it doesn't stick out much from the wall.
Date published: 2023-04-11
Rated 5 out of 5 by from Grey radiator Brilliant product enhance any room you put it into
Date published: 2023-03-21
Rated 4 out of 5 by from Smart and stylish Well made and looks great in the room Very heavy product so make sure fittings are secure in the wall.
Date published: 2021-12-02
Rated 3 out of 5 by from Damaged on arrival Top right hand corner damaged. But otherwise seems ok.
Date published: 2021-04-27
Rated 3 out of 5 by from Fitting a real pain but works ok The welded receptor for the brackets are not placed that exact that you can carefully measure the drill holes first. Also if you only use one fixing as advised the weight of the rad turns the bracket. This is the first time I`ve fitted a vertical rad and it was very difficult to get it straight because the fixings are relatively close together compared to a horizontal one and adjusting it was very difficult due to the access, weight and uncertainty of which bracket is wrong. I fitted all four brackets first and it was a real nightmare. So if you`re like me and want to see that bubble smack bang in the middle, here`s some real instructions from someone who`s actually fitted one! 1 use two screws in every bracket 2 fit one top one permanently 3 take your best guess and fit the other top one with one screw, try rad and adjust brkt (adjusting is sadly going in the side of the rawplug or elongating the hole with a file) and then fit second screw when you`re happy 4 then its fairly simple to measure for the bottom brackets making sure they are just a mm below taking weight or your bubble is all wrong again Once fitted connections were all straightforward and it seems to work well and looks good
Date published: 2020-09-02
Rated 1 out of 5 by from Looks stylish but not fit for purpose Bought this to replace an older radiator for a kitchen revamp and to use in the vertical mode. From what I have now observed these rads. should not be sold for vertical use as shown in adverts, if there are more conventional rads. on the system. The reason being; is that each panel is only connected to the in/out tubes by tiny holes ~2-3mm. So, when plumbed in from the base the incoming hot water will take the path of least resistance. Possibly plumbing in diagonally (top/bottom) might work. Of course, if plumbed horizontally incoming water would have to rise & work across the panels to reach the outlet.
Date published: 2019-10-15
