JG Speedfit Equal Straight Coupler 28mm

By JG Speedfit Product code: 12675 Pack size: Each

£6.18 Exc. VAT £5.15

Product Details

Choose this equal straight coupler to securely connect two pipes of the same size. Part of the JG Speedfit plastic push-fit system, the 28mm connector couldn’t be easier to use – simply push it fully onto the pipe, then twist the plastic nut clockwise to lock it in place.

Up to 40% faster to install than traditional methods, the equal straight connector is also easier to use in tight spaces because there’s no need for hot works and tools. Demounting the connection is simple too – you just unlock the nut by hand, push the collet towards the body of the push-fit fitting and pull the pipe to release.

JG Speedfit products blend push-fit and multi-seal technology for a reliable leak-proof connection. The extensive choice of plastic, brass and chrome fittings, tap connectors, valves and flexi hoses gives you everything you need to complete the job in no time.

By combining these products with plastic push-fit pipe, you can create a truly flexible plumbing and heating system. All products are accredited with the leading testing and approval organisations including WRAS, and are suitable for use with plastic or copper pipe.

• Connects two 28mm pipes quickly and securely

• Install or demount in seconds by hand

• Easier to install in confined spaces – no hot works or tools required

• Suitable for hot and cold water services, central heating systems and combi systems

• Compatible with Speedfit PEX and polybutylene plastic pipe (inserts required) and copper pipe

• Minimum operating temperature of 20 °C

• Maximum operating temperature of 105 °C

• Maximum operating pressure at minimum temperature of 12 bar

• Maximum operating pressure at maximum temperature of 3 bar

• BS EN 7291 Parts 1, 2, 3 and S

• WRAS-approved

• 50-year guarantee (T&Cs apply)

Technical Specification
Brand JG Speedfit
Colour White
Material Plastic
Manufacturer ID PEM0428W
Warranty (years) 50
Diameter (mm) 28
Pack Size 1
User Guide click here
Fitting Type Coupler
Equal or Reducing Equal
