Draper Mini Air Die Grinder Kit

By Draper Product code: 73067 Pack size: 15 Piece

Product Details

• Aluminium with soft-grip, 4 speeds
• Air pressure: 90 psi (6.2bar)
• Inc: 1/4" die grinder, 1/8" collet, air line connector 1/4" BSP, 2x collet wrenches, 5x 3mm 1/8" and 5x 6mm 1/4" grinding stones, case.

Compact straight die grinder kit from Draper, perfectly designed for grinding and polishing metal components. Manufactured from lightweight aluminium, attached to an ergonomic soft grip handle, providing comfort even when used for prolonged periods. Fitted with a lever block trigger for increased safety, and an adjustable 4 speed rear regulator. Attached with a 1/4" BSP airline connector which connects with the 360° rotating air inlet, helping prevent air lines from kinking when in use. All stored in a robust plastic carry case.

• Ergonomic soft grip handle
• Lightweight aluminium housing
• Lever block trigger for safety
• Adjustable 4 speed rear regulator
• Rear exhaust
• 360° rotating air inlet - anti-kink

Kit contents:
• 1 x 1/4" die grinder
• 1 x 1/8" collet
• 1 x air line connector 1/4" BSP (PCL style)
• 2 x open ended collet wrenches
• 5 x 3mm (1/8") shank grinding stones
• 5 x 6mm (1/4") shank grinding stones
• 1 x blow mould case

Draper Mini Air Die Grinder Specification:
• Collet size: 6mm
• Air inlet: 1/4" BSP
• Free speed: 25,000 rpm
• Operating air pressure: 90 psi (6.2bar)
• Average air consumption: 4cfm (113 L/min)
• Sound pressure level: 88dB(A)
• Sound power level: 99dB(A)
• Vibration level: 2.9m/s²
• Minimum hose size: 3/8" (10mm)
• Weight: 0.39kg
• Overall length: 173mm

Technical Specification
Brand Draper
Manufacturer ID 83736
Max Pressure (bar) 6.2
Weight (kg) 0.39
Sound volume 99
Delivery details

DELIVERY OPTIONS (UK mainland only)

Next Day Delivery – £5.00 or FREE for orders over £25

  • Order before 7pm Monday to Thursday for next business day delivery
  • Order Friday to Sunday before 5pm for Monday delivery
  • Orders placed after Sunday at 5pm will be delivered the following Tuesday

Pre-12pm Delivery – £10.00 or £5.00 for orders over £25, to arrive before 12pm on the scheduled days above

Saturday Delivery – £10.00 or £5.00 for orders over £25 & FREE for orders over £75 (order by 6pm Friday)

Sunday delivery – £10.00 or £5.00 for orders over £25 & FREE for orders over £75 (order by 4pm Saturday)

Times may vary for items being delivered directly from the supplier. For more information, please visit our delivery information page below.

Items over 30kg can only be delivered from Monday to Friday. If ordered before 6pm, please allow up to two business days for delivery. Orders placed after 6pm Thursday will be delivered after the weekend.

More about Delivery
Click & Collect details

Collection Details

Our opening times are 7am-8pm Monday-Friday, 7am-7pm Saturday and 9-4pm Sunday. Please check your local branch is open on the branch locator page, before you visit.

Once you have placed your order online, we’ll have it ready for you at the branch you have selected in as little as 5 minutes. We will hold your order for 14 days, after which we will automatically generate a refund to the payment type you used to place the order.

Don’t forget your mobile number – Make sure your mobile number is added so that we can text you when your order is ready to collect. Please wait for your text or email before coming to collect your items.

If an item is eligible for Next Business Day Collection in branch, the order must be placed by 7pm Monday to Thursday for collection the next day. Orders placed after 7pm on Thursday, and up to 5pm on Sunday, will be available for collection on Monday. For larger items over 30kg, please allow two business days.

Reviews
Draper Mini Air Die Grinder Kit (15 Piece) is rated 4.7 out of 5 by 7.
Rated 3 out of 5 by from Tool is great, included accessories not so much Tool works well and does the job. Included bits are not suitable for heavy steel work. The grinder will cope with a carbide burr without bogging down so i'd recommend getting one of those for it. The tool does not fit inside the included case with the included air fitting attached, or with a bit in the collet so i ground the edges of the case down to allow it to stick out.
Date published: 2021-12-14
Rated 5 out of 5 by from Air grinder Good grinder for the money
Date published: 2021-10-12
Rated 5 out of 5 by from Great little device Great little device. One of the critical issues many of these grinders have is backlash .I have not found this to be. Nice storage case, but once you have attached the air hose adapter it does not fit in the box . Thats the only downfall
Date published: 2021-06-14
Rated 5 out of 5 by from Draper Mini Die Grinder Needed it for a job that was difficult to access, done exactly what I required it for. Great wee tool.
Date published: 2021-05-08
Rated 5 out of 5 by from Bump and grind Great value die grinder kit
Date published: 2021-04-02
Rated 5 out of 5 by from Happy with purchase Gods little die grinder for tricky hard to reach areas
Date published: 2021-03-08
Rated 5 out of 5 by from Great tool Great little tool did exactly what I want would recommend
Date published: 2021-02-06
